產品介紹

電腦級 直立式不斷電系統UPS TWEM-800VA 1100VA









  • 系統容量: TWEM-800VA . 1100VA . 1500VA . 2000VA . 3000VA

  • 新樣式加大輸出容量.加增突波抑制能量.加ABM超級電池充電保護管理機制)

    系統設計: 微處理器控制全數位化高效率高可靠度INVERTER電路設計

    輸入電壓: 110VAC  或  220VAC

    輸出電壓: 110VAC  或  220VAC

    輸出頻率: 60HZ 或 50HZ (自動切換)

    液晶顯示: 輸入電壓.輸出電壓.負載百分比.電池容量.運轉狀況顯示(LCD清晰顯示市電、電池供電、電池或UPS故障)

    電池型式: 高效率閥調式免保養免加水電池(可自行更換電池的熱插拔電池設計)

    停電電池供電時間: 1台電腦可停電備用5-70分鐘(依電腦種類及運轉狀況及液晶螢幕大小,會影響停電供電時間)

    智慧型電池充電管理(ABM)系統: 超級電池管理系統,增加電池壽命,加快充電時間(2小時充電達 90%以上)

    智慧型環保節能設計:當市電停電時,在無負載時60秒後自動節能自動關機(出廠設無節能裝置)

    輸出安全插座:全天候EMI/RFI濾波器,可防止噪音所導致的數據錯誤(安規接地型安全插座)

    輸出短路保護: 市電模式:AC保險絲及電子迴路保護 電池放電模式:電子迴路保護

    雷擊.突波保護: 5000安培/360焦耳 UL 認證

    全自動穩壓器功能:自動高低電壓調節功能(AVR)全穩壓穩頻,適用於電壓不穩地區

    電池啟動功能: 直流電開機,不需市電可啟動UPS及負載機器

    自動開機功能:在電池電量耗盡時,市電恢復時,自動啓動UPS

    台電電壓過高,自動切離台電電源,以保護UPS安全

    溫度: 0℃ - 45℃

    濕度: 0 - 95%

    國際品質安規認證:  CE  CNS BSMI  EMC  EMI

    產地:騰旺企業 台灣桃園龜山廠製造 大人氣の UPS台灣製造

  • 技術標準相關準則製造測試

    中華民國國家標準(CNS BSMI)

    ANSI(American National Standards Institute)

    CSA(Canadian Standards Association)

    IEC(International Electrotechnical Commission)

    IEEE(Institute of Electrical and Electronic Engineers)

    NEMA(National Electrical Manufacturer's Association)

    UL(Underwriters' Laboratories, Inc.)

    JEC(Japaness Electrotechnical Committee)

MODEL

TWEM系列-UPS TW CELL POWER (直立式電腦級不斷電系統)

Capacity

800VA                           1100VA                        1500VA                  2000VA                          3000VA

Mode Type

Tower

INPUT

Nominal Voltage

110/115/120 Vac or 220/230/240Vac

OUTPUT

Voltage

110/115/120Vac or 220/230/240Vac re-settable via LCD panel

Frequency Regulation

Line Mode

Synchronize to AC main

Battery Mode

50Hz or 60Hz  ± 0.1Hz

Power Factor

0.625

Wave Form

Pure sine wave

Efficiency

Line Mode

> 98 %

Battery Mode

> 80%

Overload Protection

Line Mode

> 110%, then buzzer alarm and amber LED blink continuously

Battery Mode

110%~150% : 30 sec, >150% : 200ms, then UPS shutdown

Short Circuit Protection

Line Mode

Circuit breaker

Battery Mode

Electronic circuit

DC START

Cold Start

Yes

TRANSFER TIME

Typical



BATTERY

Voltage

12Vdc                            12Vdc                       24vdc                           24Vdc                               48Vdc

Type

7AH                              9AH                          7AH                            9AH                                  9AH

Quantity

1pcs                            1pcs                            2pcs                           2pcs                               4pcs

CONTROL PANEL

LCD Display

UPS status, I/P&O/P Voltage/Frequency, Load level, Battery voltage &level, Temperature, Model





AUDIBLE ALARM

Battery  Mode

Beeping every 4 seconds

Low Battery

Beeping every second

UPS Fault

Beeping continuously

Overload

Beeping twice per second

COMMUNICATION INTERFACES

Standard

USB

Multi-Interfaces Card(Option)

                         Various Comb. of RS232, SNMP, USB, Dry Contact, . Enable at the same time

ENVIRONMENT

Operation Temperature

0-40 (32-104 )

Relative Humidity

0-95% (non-condensing)

Audible Noise(At 1M)

                                                                     <35 dBA

PHYSICAL

Dimensions(W*H*D)mm

98*175*300               98*175*300            150*160*360          150*160*3601               82*285*390

Net Weight (Kg)

7                                 8.5                          15                            18                               31



NEMA Outlets

8

SAFETY CONFORMANCE

Safety Standard

EN62040-1-1

EMC

EN62040-2

Marks

BSMI
